Push Pull
Lithium Ion Push Pull Storage
The lithium iron phosphate series batteries are customized with the BMS communication protocol, which is safe and reliable, and supports the corresponding inverter system. Compared with similar products, it has the smallest volume to save space and it is easy to transport. The appearance and color can be customized.
APPLICATION
- •Uninterrupted energy
- •Home backup
- •Hospitals
- •Banks
- •Small businesses
- •Small base stations
- •Backup power systems
- •Data processing centers
| Series | Model | Standard Communication Interface | Voltage (V) | Standard Capacity (Ah) | Standard Charge Current (A) | Standard Discharge Current (A) | Standard Power (Wh) | Max Charge Current (A) | Max Discharge Current (A) | BMS (A) | Weight±3% (KG) | Dimensions±2 (mm) | Datasheet |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 51.2V | TLLFP400-51.2 | RS485/RS232/CAN | 51.2 | 400 | 60 | 60 | 20480 | 200 | 200 | 200 | 155 | 619*252*888 | |
| 51.2V | TLLFP300-51.2 | RS485/RS232/CAN | 51.2 | 300 | 60 | 60 | 15360 | 200 | 200 | 200 | 117 | 554*252*714 |
